Description：IC RF SWITCH SP4T 3GHZ
Series：SPnT
Mfr：Radiall USA, Inc.
Package：Bulk

SKU:7eaae9a169f6 Category: RF Switches Brand: Radiall USA, Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：IC RF SWITCH SP4T 3GHZ
Series：SPnT
Mfr：Radiall USA, Inc.
Package：Bulk
Product Status：Obsolete
RF Type：General Purpose
Topology：-
Circuit：SP4T
Frequency Range：0Hz ~ 3GHz
Isolation：80dB (min)
Insertion Loss：0.2dB (max)
Test Frequency：3GHz
Impedance：50Ohm
Voltage - Supply：10.2V ~ 13V
Operating Temperature：-40°C ~ 85°C
Mounting Type：-
Package / Case：Module
P1dB：-
IIP3：-
Features：-
Supplier Device Package：-
Grade：-
Qualification：-

Download product information

R574302405

Overview

The Radiall R574302405 is a SP4T coaxial switch from the Terminated Ramses series, designed for RF applications up to 3 GHz. It utilizes SMA connectors and features a D-sub connector interface. The device operates on 12Vdc power and maintains a normally open state. Constructed with terminated architecture, it ensures signal integrity within its specified frequency range.
