R574302415

$838.30

Description：IC RF SWITCH SP4T 3GHZ
Series：SPnT
Mfr：Radiall USA, Inc.
Package：Bulk

SKU:cfef637268b8 Category: RF Switches Brand: Radiall USA, Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：IC RF SWITCH SP4T 3GHZ
Series：SPnT
Mfr：Radiall USA, Inc.
Package：Bulk
Product Status：Obsolete
RF Type：General Purpose
Topology：-
Circuit：SP4T
Frequency Range：0Hz ~ 3GHz
Isolation：80dB (min)
Insertion Loss：0.2dB (max)
Test Frequency：3GHz
Impedance：50Ohm
Voltage - Supply：10.2V ~ 13V
Operating Temperature：-40°C ~ 85°C
Mounting Type：-
Package / Case：Module
P1dB：-
IIP3：-
Features：-
Supplier Device Package：-
Grade：-
Qualification：-

Download product information

R574302415

Overview

The R574302415 is a general-purpose RF switch IC manufactured by Radiall USA, Inc. It features an SP4T (Single-Pole Four-Throw) topology designed for operation up to 3 GHz. The component utilizes the Terminated Ramses architecture with SMA connectors and includes a D-sub connector interface. It operates on 12Vdc power supply.
