R5F100LHGFA#30

Microcontrollers Overview

The R5F100LHGFA#30 is a 16-bit microcontroller from the Renesas RL78/G13 series. It features an internal Flash program memory size of 192 kB and SRAM data memory of 16 kB. The device operates with a maximum clock frequency of 32 MHz and supports a supply voltage range of 1.6 V to 5.5 V. It is housed in a 64-pin LFQFP package and includes 58 I/O lines. The unit supports CSI, I2C, LIN, and UART interfaces, along with a 12-channel ADC offering 8-bit and 10-bit resolution. The operating temperature range spans from -40°C to +85°C.

Microcontrollers Feature Summary

• Integrates high-speed 16-bit processing with low-power consumption capabilities for efficient system control.
• Provides versatile communication interfaces including CSI, I2C, LIN, and UART for flexible peripheral connectivity.
• Features integrated analog-to-digital conversion with selectable resolution for precise signal monitoring.

Microcontrollers Applications

• Automotive body electronics and lighting control systems
• Industrial motor control and sensor interface modules
• Consumer appliance main control units

Microcontrollers Procurement Notes

Verify component authenticity through authorized distributors or direct manufacturer channels. Confirm RoHS compliance status and moisture sensitivity level prior to assembly. Ensure storage conditions meet specified humidity requirements to prevent damage during handling and soldering processes.

Microcontrollers Selection Notes

Select this model when a balance of moderate code capacity and extensive I/O is required within a 64-pin footprint. Consider the specific voltage range and temperature rating against environmental constraints. Evaluate interface availability against peripheral needs before choosing alternative pin counts.

Microcontrollers Part Context

This component belongs to the RL78/G13 family, designed for general-purpose applications requiring robust performance. It shares architectural similarities with other members like the R5F100LHAFA#30 but differs in memory configuration and package options. The series targets cost-sensitive markets demanding reliable 16-bit processing.

Microcontrollers FAQ

What is the maximum operating frequency of the R5F100LHGFA#30?

The maximum clock frequency is 32 MHz.

Does this MCU support LIN bus communication?

Yes, the device includes hardware support for LIN bus interfaces alongside CSI, I2C, and UART.
