R5F100MHAFA#70

Microcontrollers Overview

The R5F100MHAFA#70 is a 16-bit general-purpose microcontroller from the Renesas RL78/G13 family. It features a 32 MHz maximum clock frequency and integrates 192 KB of FLASH program memory with 16 KB of data RAM. The device operates within a supply voltage range of 1.6 V to 5.5 V and supports an operating temperature range of -40°C to +85°C. It utilizes an 80-pin LQFP package and includes 17 ADC channels with selectable 8-bit or 10-bit resolution.

Microcontrollers Feature Summary

• Integrates high-capacity 192 KB FLASH memory for complex application storage
• Supports low-voltage operation down to 1.6 V for energy-efficient designs
• Includes versatile analog peripherals with multi-resolution ADC capabilities

Microcontrollers Applications

• General-purpose industrial control systems
• Consumer electronics requiring robust 16-bit processing
• Embedded applications in automotive environments

Microcontrollers Procurement Notes

Verify the specific suffix #70 against official Renesas documentation to confirm packaging and moisture sensitivity level details. Ensure compatibility with existing PCB footprints for the 80-LQFP package. Cross-reference the part number with current datasheets to validate pin assignments and electrical characteristics before finalizing procurement orders.

Microcontrollers Selection Notes

Select this component when 192 KB of program memory is required within the RL78/G13 architecture. It is suitable for designs needing 16-bit processing at 32 MHz with extensive I/O options via the 80-pin package. Consider the 1.6 V to 5.5 V operating range for flexible power supply integration in mixed-voltage systems.

Microcontrollers Part Context

This microcontroller belongs to the RL78/G13 series, designed for general-purpose applications. It offers a balance of performance and peripheral richness typical of the RL78 family. The 80-LQFP package provides ample connectivity for complex embedded tasks while maintaining a compact form factor suitable for space-constrained electronic devices.

Microcontrollers Replacement Considerations

Consult official Renesas substitution guides for compatible alternatives within the RL78/G13 family. Verify pin-to-pin compatibility and memory size equivalence when considering substitutes such as other variants in the same series.
