R5F101GGAXXXNA#40 is listed in the Microcontrollers range at ChipApex. The manufacturer field lists Renesas Electronics Corporation. Its product description is IC MCU 16BIT 128KB FLASH 48HWQFN. Review the specifications below when checking this part for your BOM.
Microcontrollers specifications for R5F101GGAXXXNA#40
- Description：IC MCU 16BIT 128KB FLASH 48HWQFN
- Series：RL78/G13
- Mfr：Renesas Electronics Corporation
- Package：Tape & Reel (TR)
- Core Processor：RL78
- Core Size：16-Bit
- Speed：32MHz
- Connectivity：CSI, I2C, LINbus, UART/USART
- Peripherals：DMA, LVD, POR, PWM, WDT
- Number of I/O：34
- Program Memory Size：128KB (128K x 8)
- Program Memory Type：FLASH
- EEPROM Size：-
- RAM Size：12K x 8
- Voltage - Supply (Vcc/Vdd)：1.6V ~ 5.5V
- Data Converters：A/D 10x8/10b
- Oscillator Type：Internal
- Operating Temperature：-40°C ~ 85°C (TA)
- Mounting Type：Surface Mount
- Supplier Device Package：48-HWQFN (7x7)
- Package / Case：48-WFQFN Exposed Pad
- Grade：-
- Qualification：-
Microcontrollers datasheet and documents for R5F101GGAXXXNA#40
Microcontrollers Overview
The R5F101GGANA#40 is a 16-bit microcontroller from the Renesas RL78/G13 family, housed in a 48-pin HWQFN package. It features 128 kB of Flash program memory and 12 kB of SRAM data RAM. The device operates with a maximum clock frequency of 32 MHz and supports an input/output count of 44 I/O pins. It includes a 10-channel ADC with 8-bit or 10-bit resolution. The operating voltage range spans from 1.6 V to 5.5 V, and it functions within a temperature range of -40°C to +85°C.
Microcontrollers Feature Summary
- Integrates high-speed 16-bit CPU core for efficient code execution
- Includes versatile peripheral interfaces such as I2C and UART
- Supports low-voltage operation suitable for battery-powered applications
Microcontrollers Applications
- General-purpose embedded control systems
- Industrial instrumentation modules
- Consumer electronic devices requiring robust MCU performance
Microcontrollers Procurement Notes
Verify the exact suffix against official Renesas documentation to confirm pinout and electrical specifications. Confirm RoHS compliance status through current datasheets. Check for obsolescence notices or lifecycle changes before finalizing procurement plans.
Microcontrollers Selection Notes
Select this component when 128 kB of program memory and 12 kB of RAM are required within a compact 48-pin form factor. Ensure the application environment stays within the specified -40°C to +85°C temperature range. Verify that the 1.6 V to 5.5 V supply voltage aligns with system power design constraints.
Microcontrollers Part Context
This part belongs to the RL78/G13 series, designed for general-purpose use. It offers a balance of processing power and peripheral integration. The HWQFN-48 package provides a small footprint for space-constrained designs while maintaining thermal performance.
Microcontrollers Replacement Considerations
Consult official substitution guides for compatible parts within the RL78 family. Verify pin compatibility and memory size differences before replacing.
