R5F101LCDFB#X0

Microcontrollers Overview

The R5F101LCDFB#X0 is a 16-bit microcontroller from the Renesas RL78/G13 series. It features a 32KB flash program memory and 2KB RAM, operating at a maximum clock frequency of 32MHz. The device supports a supply voltage range of 1.6V to 5.5V and includes an internal oscillator. It provides 48 I/O pins and integrates peripherals such as DMA, LVD, POR, PWM, and WDT. Connectivity options include CSI, I2C, LINbus, and UART/USART interfaces. The unit is housed in a 64-LQFP package with dimensions of 12x12mm and operates within a temperature range of -40°C to 85°C.

Microcontrollers Feature Summary

• Integrates a 16-bit RL78 core with up to 32MHz processing speed for efficient control applications.
• Includes built-in connectivity interfaces supporting CSI, I2C, LINbus, and UART/USART communication protocols.
• Features integrated analog-to-digital conversion capabilities with configurable resolution options.

Microcontrollers Applications

• General-purpose embedded control systems
• Industrial automation controllers
• Consumer electronics devices

Microcontrollers Procurement Notes

Verify component authenticity through authorized distributors or direct manufacturer channels. Confirm RoHS compliance status and check for specific packaging requirements such as tape and reel specifications. Ensure the part number suffix matches the required package variant. Review datasheets for latest revision updates and pinout configurations before integration into design schematics.

Microcontrollers Selection Notes

Select this model when a 16-bit architecture with moderate memory capacity is required. Consider the 64-pin LQFP package for board space constraints. Evaluate peripheral needs against available CSI, I2C, and UART interfaces. Verify voltage compatibility with the 1.6V to 5.5V operating range. Compare performance metrics against other RL78/G13 variants if higher memory or different pin counts are necessary.

Microcontrollers Part Context

This component belongs to the RL78/G13 family of 16-bit microcontrollers designed by Renesas Electronics. The series targets cost-sensitive applications requiring robust performance and low power consumption. The G13 group typically offers a balance of processing capability and peripheral integration suitable for various industrial and consumer markets.
