R5F211B3XXXSP#U0

Microcontrollers Overview

The R5F211B3XXXSP#U0 is a 16-bit microcontroller from the Renesas R8C/1x/1B series, featuring an R8C CPU core. It integrates 12KB of flash memory and 768 bytes of RAM within a 20-LSSOP package. The device supports a maximum clock frequency of 20MHz and operates on a supply voltage range of 2.7V to 5.5V. It includes four 10-bit analog-to-digital converter channels and an internal oscillator. Standard peripherals include I2C, SIO, SSU, and UART/USART interfaces, alongside LED, POR, voltage detection, and watchdog timer functions.

Microcontrollers Feature Summary

• Integrates a 16-bit R8C CPU core with embedded flash memory for program storage.
• Includes multiple communication interfaces such as I2C, SIO, SSU, and UART/USART.
• Features built-in analog-to-digital conversion capabilities with four channels.
• Supports low-voltage operation down to 2.7V at reduced frequencies.

Microcontrollers Applications

• General-purpose embedded control systems
• Industrial monitoring devices
• Consumer electronics controllers

Microcontrollers Procurement Notes

Verify component authenticity through authorized Renesas distributors or direct manufacturer channels. Confirm RoHS compliance status and check for End-of-Life notices, as this specific part number may be discontinued. Ensure packaging specifications match design requirements before finalizing procurement orders.

Microcontrollers Selection Notes

Select this component for applications requiring a 16-bit architecture with moderate memory capacity in a compact surface-mount package. Consider the 20MHz processing speed and available peripheral set against system timing and interface needs. Evaluate thermal performance within the specified operating temperature range during hardware design.

Microcontrollers Part Context

This microcontroller belongs to the R8C/1B group, which represents a legacy line of 16-bit MCUs from Renesas Electronics. These devices are designed for cost-sensitive applications requiring reliable processing power. New designs are often directed toward modern alternatives like the RL78/G12 series, while existing products may continue support for established customer bases.

Microcontrollers Replacement Considerations

Consult official Renesas documentation for confirmed substitute part numbers within the same family or recommended newer generations. Verify pin compatibility and software migration paths when transitioning to alternative components.
