R5F56604CGFN#30

Microcontrollers Overview

The R5F56604CGFN#30 is a 32-bit microcontroller from the Renesas RX660 series, utilizing the RXv3 core. It features 512 kB of Flash program memory and 128 kB of data RAM. The device operates at a maximum clock frequency of 120 MHz and supports a supply voltage range of 2.7 V to 5.5 V. It is housed in an LFQFP-80 package with 71 I/O pins. Key peripherals include a 12-bit ADC with 17 channels, a 12-bit DAC with 2 channels, CAN bus, I2C, RSPI, SCI, and a watchdog timer. Operating temperatures range from -40°C to +85°C.

Microcontrollers Feature Summary

• Integrates high-performance RXv3 32-bit CPU core for efficient processing
• Includes integrated analog-to-digital and digital-to-analog converters
• Supports multiple communication interfaces including CAN and serial protocols

Microcontrollers Applications

• Industrial automation control systems
• Automotive electronic control units
• General-purpose embedded applications requiring robust connectivity

Microcontrollers Procurement Notes

Verify the specific suffix against official Renesas documentation to confirm package type and temperature grade. Ensure compatibility with existing board layouts for the LFQFP-80 footprint. Confirm moisture sensitivity level handling requirements during assembly. Cross-reference part numbers with current manufacturer catalogs to avoid obsolete variants.

Microcontrollers Selection Notes

Select this component when a balance of moderate memory capacity and extensive peripheral connectivity is required. The RXv3 core offers improved performance over previous generations while maintaining software compatibility. Consider the 5.5V operating limit for direct interfacing with higher voltage logic domains without additional level shifting.

Microcontrollers Part Context

This microcontroller belongs to the RX660 family, designed for applications demanding high reliability and real-time control capabilities. The series is characterized by its advanced security features and low power consumption modes. It serves as a scalable solution within the broader Renesas RX ecosystem, allowing for pin-to-pin upgrades or downgrades depending on project memory needs.

Microcontrollers Replacement Considerations

Consult official Renesas substitution guides for verified equivalents. Direct replacements must match the RXv3 architecture and LFQFP-80 package constraints.
