R7F101GEG4CNP#AA0 is listed in the Microcontrollers range at ChipApex. The manufacturer field lists Renesas Electronics Corporation. Its product description is 16BIT MCU RL78/G24 128K 40HWQFN. Review the specifications below when checking this part for your BOM.
Microcontrollers specifications for R7F101GEG4CNP#AA0
- Description：16BIT MCU RL78/G24 128K 40HWQFN
- Series：RL78/G24
- Mfr：Renesas Electronics Corporation
- Package：Tray
- Core Processor：RL78
- Core Size：16-Bit
- Speed：48MHz
- Connectivity：CSI, I2C, LINbus, SPI, UART/USART
- Peripherals：LVD, POR, PWM, WDT
- Number of I/O：33
- Program Memory Size：128KB (128K x 8)
- Program Memory Type：FLASH
- EEPROM Size：4K x 8
- RAM Size：12K x 8
- Voltage - Supply (Vcc/Vdd)：1.6V ~ 5.5V
- Data Converters：A/D 19x8/10b/12b; D/A 3x8b/10b
- Oscillator Type：Internal
- Operating Temperature：-40°C ~ 125°C (TA)
- Mounting Type：Surface Mount
- Supplier Device Package：40-HWQFN (6x6)
- Package / Case：40-WFQFN Exposed Pad
- Grade：-
- Qualification：-
Microcontrollers datasheet and documents for R7F101GEG4CNP#AA0
Microcontrollers Overview
The R7F101GEG4CNP#AA0 is a 16-bit microcontroller from the Renesas RL78/G24 series. It features a 48MHz CPU core, 64KB of flash memory, and 12KB of RAM. The device includes an internal oscillator and supports supply voltages from 1.6V to 5.5V. It offers various communication interfaces including CSI, I2C, LINbus, SPI, and UART/USART. The component is housed in a 48-HWQFN package with dimensions of 7x7mm and operates within a temperature range of -40°C to 85°C.
Microcontrollers Feature Summary
- Integrated high-performance 16-bit RL78 core for efficient processing
- Built-in analog-to-digital converter with multiple resolution options
- Comprehensive set of peripheral functions including PWM and watchdog timer
Microcontrollers Applications
- General-purpose control systems
- Industrial automation devices
- Consumer electronics appliances
Microcontrollers Procurement Notes
Verify current availability status as this part may be subject to discontinuation notices. Confirm package type and pinout compatibility during integration. Check for official product change notifications regarding manufacturing updates or end-of-life declarations before finalizing procurement plans.
Microcontrollers Selection Notes
Select this model for applications requiring a balance of processing power and low voltage operation. Ensure the design accommodates the specific thermal requirements of the HWQFN package. Compare pin counts and peripheral sets against other RL78/G24 variants to confirm optimal fit for interface needs.
Microcontrollers Part Context
This component belongs to the RL78/G24 family, which provides enhanced analog capabilities and rich timer functions compared to previous generations. The series is designed for general-purpose use with a focus on low power consumption and high integration levels suitable for compact electronic designs.
Microcontrollers Replacement Considerations
Consult official Renesas documentation for confirmed substitute part numbers. Verify functional equivalence and pin compatibility before considering alternative components from the same family.
