R7F7016114AFE#BA3

Microcontrollers Overview

The R7F7016114AFE#BA3 is a 32-bit microcontroller from the Renesas RH850/F1KM-S1 series, utilizing the RH850G3KH core processor. It operates at a maximum speed of 120MHz and features 512KB of flash program memory, 64KB of EEPROM, and 64KB of RAM. The device supports a supply voltage range of 3V to 5.5V and includes integrated A/D converters (4x10b, 8x12b). Connectivity options include CANbus, CSI, I2C, LINbus, SPI, and UART/USART interfaces. It offers 33 I/O lines and peripherals such as DMA, LVD, PWM, and WDT. The component is housed in a 48-LQFP package and functions within an operating temperature range of -40°C to 105°C.

Microcontrollers Feature Summary

• Integrates high-speed 120MHz processing capability with robust automotive-grade reliability for complex control tasks.
• Provides extensive connectivity through multiple communication protocols including CANbus, LINbus, and SPI for seamless system integration.
• Features comprehensive analog-to-digital conversion capabilities with mixed resolution support for precise sensor interfacing.

Microcontrollers Applications

• Body electronics control modules
• Instrument cluster systems
• Door control units

Microcontrollers Procurement Notes

Verify the specific suffix #BA3 against official Renesas documentation to confirm package type and tape-and-reel specifications. Confirm current availability status as distribution channels may list varying stock levels or end-of-life notices. Ensure compliance with RoHS3 standards and check for any recent product change notifications affecting manufacturing or labeling.

Microcontrollers Selection Notes

Select this component when a balance of moderate pin count and substantial memory is required for body applications. The 48-pin LQFP package suits space-constrained designs compared to larger QFP variants. Verify that the 120MHz clock speed meets real-time processing requirements and that the available I/O count satisfies interface needs without external multiplexing.

Microcontrollers Part Context

This part belongs to the RH850/F1KM-S1 family, designed specifically for automotive body applications. It shares architectural similarities with other RH850 G3K-based devices but differs in memory size and package configuration. The series emphasizes functional safety and low power consumption suitable for embedded control environments.

Microcontrollers Replacement Considerations

Consult official cross-reference guides for direct substitutes within the RH850/F1KM series. Verify pin compatibility and memory mapping before substituting with variants like R7F7016953AFP-C#BA1, noting differences in package dimensions and peripheral availability.

Microcontrollers FAQ

What is the maximum operating frequency of the RH850G3KH core in this model?

The maximum operating frequency is 120MHz.

Does this microcontroller support LINbus communication?

Yes, the device includes integrated LINbus interface capabilities alongside CANbus and other standard protocols.
