R7F7016233AFP-C#BA3

Microcontrollers Overview

The R7F7016233AFP-C#BA3 is a 32-bit microcontroller from the Renesas RH850/F1K series, designed for automotive applications. It features the RH850G3KH core operating at 120MHz. The device includes 1MB of flash memory, 64KB of EEPROM, and 96KB of RAM. It is housed in a 144-LQFP package with 120 I/O pins. Supply voltage ranges from 3V to 5.5V, and it operates within a temperature range of -40°C to 105°C. Connectivity options include CANbus, LINbus, SPI, UART/USART, I2C, and CSI.

Microcontrollers Feature Summary

• Supports ASIL B functional safety standards for automotive chassis systems
• Integrates high-performance 32-bit RH850 core with 120MHz operation
• Includes comprehensive peripheral set with DMA, PWM, and watchdog timer

Microcontrollers Applications

• Automotive chassis control systems
• Body electronics modules
• Safety-critical embedded applications requiring ASIL B compliance

Microcontrollers Procurement Notes

Verify current availability status as supply may be limited or restricted. Confirm exact ordering suffixes match required packaging and temperature grades. Check datasheet for specific pinout and electrical characteristics relevant to your design. Ensure compatibility with existing development tools and software libraries before procurement.

Microcontrollers Selection Notes

Select this component when ASIL B compliance is required for chassis or body applications. Compare memory sizes against other RH850/F1K variants if different storage capacities are needed. Verify package dimensions and pin counts fit the target PCB layout. Consider thermal performance within the specified operating temperature range.

Microcontrollers Part Context

This part belongs to the RH850/F1K family, targeting mid-range automotive applications. It shares architectural similarities with other RH850 cores but offers specific memory and peripheral configurations. The F1K series emphasizes functional safety and security for vehicle control units.

Microcontrollers Replacement Considerations

Check for direct substitutes within the RH850/F1K family with matching pinouts and memory sizes. Verify that any replacement maintains ASIL B certification and compatible peripheral sets. Consult official cross-reference tools for validated alternatives.
