RC-ANT-868-BE is listed in the Antennas RF range at ChipApex. The manufacturer field lists RadioControlli. Its product description is 868MHz Spring Helical Antenna. Review the specifications below when checking this part for your BOM.
Antennas RF specifications for RC-ANT-868-BE
- Description：868MHz Spring Helical Antenna
- Series：-
- Mfr：RadioControlli
- Package：Case
- RF Family/Standard：General ISM
- Frequency Group：-
- Frequency (Center/Band)：868MHz
- Frequency Range：855MHz ~ 890MHz
- Antenna Type：Bead
- Number of Bands：-
- VSWR：2
- Return Loss：-
- Gain：2.15dBi
- Features：-
- Termination：PCB
- Ingress Protection：-
- Grade：-
- Qualification：-
- Mounting Type：Through Hole
- Height (Max)：0.441" (11.20mm)
- Applications：ISM
- Power - Max：-
Antennas RF datasheet and documents for RC-ANT-868-BE
Antennas RF Overview
The RC-ANT-868-BE is a spring helical antenna designed for 868MHz wireless data transmission and measurement communication systems. Manufactured by RadioControlli, this component operates within the ISM band, providing reliable RF performance for IoT applications. It features a bead PCB through-hole mounting style, suitable for integration into various electronic devices requiring stable signal connectivity at the specified frequency.
Antennas RF Feature Summary
- Spring helical design for compact form factor
- Optimized for 868MHz ISM band operations
- Through-hole mounting configuration
Antennas RF Applications
- Wireless data transmission systems
- Meter communication networks
- IoT module integration
Antennas RF Procurement Notes
Verify the specific datasheet version from RadioControlli to confirm mechanical dimensions and connector details. Ensure compatibility with the target PCB layout for through-hole assembly. Cross-reference part numbers with authorized distributors to avoid counterfeit components. Confirm environmental ratings if deployment involves extreme temperatures.
Antennas RF Selection Notes
Select this model when a low-profile spring antenna is required for 868MHz applications. Consider the through-hole mounting requirement against available board space. Evaluate VSWR performance specifications in the official datasheet relative to system sensitivity requirements. Compare physical size constraints against alternative SMA or FPC variants.
Antennas RF Part Context
This antenna belongs to the broader family of 868MHz RF components offered by RadioControlli. It complements other models like the RC-ANT-868-SMA and RC-ANT-868-FPC, offering distinct mounting and form-factor options. The series supports diverse IoT and metering applications across different industrial sectors.
Antennas RF Replacement Considerations
RC-ANT-868-SMA offers similar frequency coverage with an SMA connector interface. RC-ANT-868-FPC provides a flexible printed circuit alternative. Verify mechanical fit and electrical performance before substituting.
