Product Detailed Parameters
- Description：LINE FILTER 240VAC SURFACE MOUNT
- Series：-
- Mfr：R-K Electronics, Inc.
- Package：Box
- Filter Type：Three Phase (Delta)
- Configuration：-
- Voltage - Rated DC：-
- Voltage - Rated AC：240V
- Current：-
- Frequency - Operating：50 ~ 60Hz
- Applications：General Purpose
- Approval Agency：cURus
- Operating Temperature：-40°C ~ 60°C
- Mounting Type：Surface Mount
- Termination Style：Wire Leads
- Inductance：-
- Voltage - Rated AC (Phase to Ground/Neutral)：-
- Voltage - Rated AC (Phase to Phase)：-
Download product information
Overview
The RCD218-30 is a three-phase (Delta) EMC/EMI line filter manufactured by R-K Electronics, Inc. Designed for general-purpose applications, this component operates at 240VAC with a frequency range of 50 to 60Hz. It features wire leads for connection and serves as a transient voltage filter and snubber. The unit is classified as a power line filter module intended for electrical control environments.
Feature Summary
- Provides electromagnetic compatibility filtering for three-phase delta systems
- Functions as a transient voltage filter and snubber circuit
- Utilizes wire lead connections for installation
Applications
- General-purpose electrical control applications
- Three-phase power line noise suppression
- Transient voltage protection in industrial controls
Procurement Notes
Verify the specific suffix variant required for your application, such as the V designation which may indicate surface mount or specific packaging differences compared to the base model. Confirm that the 240VAC rating aligns with your system voltage. Ensure the Delta configuration matches your three-phase wiring scheme before procurement.
Selection Notes
Select this component when three-phase EMI/RFI suppression is required for 240VAC systems operating at standard utility frequencies. Consider the wire lead termination style for integration into existing control panels. Evaluate the need for transient voltage suppression capabilities alongside standard line filtering requirements for robust performance.
Part Context
This part belongs to the RCD series of RC networks produced by R-K Electronics, Inc., a manufacturer specializing in electronic automation control components. The series includes various filters and snubbers designed for the electrical controls industry, offering solutions for noise reduction and voltage stabilization in industrial settings.
Replacement Considerations
Public confirmed substitute part numbers are not available in the provided documentation. Verify compatibility with existing panel space and wiring configurations if sourcing alternatives from other manufacturers.
