Product Detailed Parameters
- Description：LINE FILTER 150VAC SURFACE MOUNT
- Series：-
- Mfr：R-K Electronics, Inc.
- Package：Bulk
- Filter Type：Single Phase
- Configuration：-
- Voltage - Rated DC：-
- Voltage - Rated AC：150V
- Current：-
- Frequency - Operating：50 ~ 60Hz
- Applications：General Purpose
- Approval Agency：cURus
- Operating Temperature：-40°C ~ 85°C
- Mounting Type：Surface Mount
- Termination Style：Wire Leads
- Inductance：-
- Voltage - Rated AC (Phase to Ground/Neutral)：-
- Voltage - Rated AC (Phase to Phase)：-
Download product information
Overview
The RCS7C-6V is a single-phase EMC/EMI line filter module manufactured by R-K Electronics, Inc. It is designed for surface mount applications and operates with a rated AC voltage of 150V at frequencies between 50 and 60Hz. The component utilizes wire leads for connection and incorporates a capacitance value of 0.47 microfarads alongside a resistance of 330 ohms to provide effective noise suppression in power line circuits.
Feature Summary
- Single-phase EMC/EMI line filtering capability
- Surface mount construction for PCB integration
- Wire lead termination style
Applications
- Power supply input stages requiring EMI suppression
- Electronic equipment compliant with single-phase AC standards
- Industrial control systems utilizing 150V AC inputs
Procurement Notes
Verify the specific datasheet version from R-K Electronics, Inc. to confirm mechanical dimensions and mounting hole locations. Ensure the selected variant matches the required 150VAC rating and 0.47MFD capacitance specification for your circuit design. Cross-reference the part number RCS7C-6V with official manufacturer documentation to validate RoHS compliance status and current production activity before finalizing procurement orders.
Selection Notes
Select this component when a compact, surface-mount solution is required for single-phase AC line filtering. The 150VAC rating defines the maximum operating voltage limit. Consider the 0.47MFD capacitance and 330-ohm resistance values for impedance matching. Verify that the wire lead configuration fits the available PCB layout space and connector requirements.
Part Context
This component belongs to the RCS series of power line filter modules from R-K Electronics, Inc. These modules are engineered to attenuate electromagnetic interference in AC power lines. The RCS7C-6V specifically addresses single-phase applications, offering a balance of filtering performance and physical footprint suitable for modern electronic assemblies.
Replacement Considerations
Consult official substitution lists from R-K Electronics, Inc. for direct equivalents. Verify that any alternative part maintains the same 150VAC rating, single-phase configuration, and surface mount form factor to ensure compatibility with existing board designs.
