Product Detailed Parameters
- Description：LINE FILTER 600VAC SURFACE MOUNT
- Series：-
- Mfr：R-K Electronics, Inc.
- Package：Box
- Filter Type：Three Phase (Wye)
- Configuration：-
- Voltage - Rated DC：-
- Voltage - Rated AC：600V
- Current：-
- Frequency - Operating：50 ~ 60Hz
- Applications：General Purpose
- Approval Agency：cURus
- Operating Temperature：-40°C ~ 85°C
- Mounting Type：Surface Mount
- Termination Style：Wire Leads
- Inductance：-
- Voltage - Rated AC (Phase to Ground/Neutral)：-
- Voltage - Rated AC (Phase to Phase)：-
Download product information
Overview
The RCY618-30VR is a three-phase (Wye) power line filter module manufactured by R-K Electronics, Inc. Designed for electromagnetic compatibility (EMC) and electromagnetic interference (EMI) suppression, this component operates at a voltage rating of 600VAC within the 50 to 60Hz frequency range. It features a capacitance value of 0.47MFD and utilizes wire leads for connection.
Feature Summary
- Provides EMC/EMI noise suppression for three-phase electrical systems
- Designed for Wye configuration power line applications
- Utilizes wire lead termination for integration
Applications
- Three-phase power line filtering
- Electromagnetic interference suppression in industrial controls
- Electromagnetic compatibility enhancement for automation equipment
Procurement Notes
Verify the specific datasheet RCY618-30VR.pdf from R-K Electronics, Inc. to confirm technical specifications and compliance standards before procurement. Ensure the application environment matches the 600VAC rating and Wye configuration requirements. Cross-reference part numbers with official manufacturer documentation to avoid counterfeit or obsolete components.
Selection Notes
Select this component for applications requiring three-phase EMI filtering in Wye configurations. Confirm that the system voltage does not exceed 600VAC and the operating frequency aligns with 50-60Hz specifications. Evaluate the need for wire lead connections versus other termination methods based on the assembly design constraints.
Part Context
R-K Electronics, Inc. manufactures electronic automation controls for the electrical controls industry. The RCY618-30VR belongs to their Power Line Filter Modules series, designed to support voltage relays and control systems. This product line focuses on providing reliable filtering solutions for industrial automation environments.
FAQ
What is the phase configuration for the RCY618-30VR?
The RCY618-30VR is designed for three-phase Wye configuration applications.
What is the maximum voltage rating for this filter module?
The component has a voltage rating of 600VAC.
