Product Detailed Parameters
- Description：LINE FILTER 200VDC SURFACE MOUNT
- Series：-
- Mfr：R-K Electronics, Inc.
- Package：Box
- Filter Type：DC
- Configuration：-
- Voltage - Rated DC：200V
- Voltage - Rated AC：-
- Current：-
- Frequency - Operating：-
- Applications：General Purpose
- Approval Agency：-
- Operating Temperature：-40°C ~ 85°C
- Mounting Type：Surface Mount
- Termination Style：Wire Leads
- Inductance：-
- Voltage - Rated AC (Phase to Ground/Neutral)：-
- Voltage - Rated AC (Phase to Phase)：-
Download product information
Overview
The RDS1A-12 is a surface-mount surge protection device manufactured by R-K Electronics, Inc. It functions as a line filter rated for 200 VDC applications. The component is designed to suppress transient voltage spikes and electromagnetic interference on DC power lines. Its compact form factor allows for direct integration onto printed circuit boards without requiring through-hole mounting techniques.
Feature Summary
- Surface mount construction for automated PCB assembly
- Integrated filtering capability for DC power lines
- Designed for transient voltage suppression
Applications
- DC power input stages in electronic equipment
- Surge protection for low-voltage DC circuits
- Electromagnetic interference filtering in industrial control systems
Procurement Notes
Verify the specific datasheet version with the manufacturer or authorized distributor before procurement. Confirm that the 200 VDC rating aligns with your system's maximum operating voltage. Ensure the surface-mount footprint matches your PCB design requirements. Request official documentation to validate performance characteristics against your application standards.
Selection Notes
Select this component when a surface-mount solution is required for DC line filtering. Consider the 200 VDC rating limit when designing power architectures. Evaluate the physical dimensions to ensure compatibility with board space constraints. Compare alternative packages if higher current handling or different mounting styles are necessary for the specific design.
Part Context
This part belongs to the R-K Electronics series of surge protection devices. These components are categorized under power line filters and suppressors. The product line focuses on protecting sensitive electronics from voltage transients. The RDS1A-12 represents a specific variant optimized for 200 VDC surface-mount applications.
Replacement Considerations
Consult the manufacturer's cross-reference list for verified substitutes. Verify that any replacement maintains the 200 VDC rating and surface-mount package. Ensure electrical parameters match the original specifications to prevent circuit failure.
