REA0611330M035K

REA0611330M035K is listed in the Aluminum Electrolytic Capacitors range at ChipApex. The manufacturer field lists KYOCERA AVX. Its product description is CAP ALUM 33UF 20% 35V RADIAL TH. Review the specifications below when checking this part for your BOM.

Aluminum Electrolytic Capacitors specifications for REA0611330M035K

• Description：CAP ALUM 33UF 20% 35V RADIAL TH
• Series：REA
• Mfr：KYOCERA AVX
• Package：Cut Tape (CT),Tape & Box (TB)
• Capacitance：33 µF
• Tolerance：±20%
• Voltage - Rated：35 V
• ESR (Equivalent Series Resistance)：-
• Lifetime @ Temp.：3000 Hrs @ 105°C
• Operating Temperature：-40°C ~ 105°C
• Polarization：Polar
• Ratings：-
• Applications：General Purpose
• Ripple Current @ Low Frequency：100 mA @ 120 Hz
• Ripple Current @ High Frequency：160 mA @ 10 kHz
• Lead Spacing：0.098" (2.50mm)
• Size / Dimension：0.248" Dia (6.30mm)
• Height - Seated (Max)：0.472" (12.00mm)
• Surface Mount Land Size：-
• Mounting Type：Through Hole
• Package / Case：Radial, Can
• Impedance：-

Aluminum Electrolytic Capacitors datasheet and documents for REA0611330M035K
