REC5-1205DRW/H2/A

REC5-1205DRW/H2/A is listed in the DC DC Converters range at ChipApex. The manufacturer field lists Recom Power. Its product description is DC DC CONVERTER +/-5V 5W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for REC5-1205DRW/H2/A

• Description：DC DC CONVERTER +/-5V 5W
• Series：ECONOLINE REC5 (5W)
• Mfr：Recom Power
• Package：Tube
• Type：Isolated Module
• Number of Outputs：2
• Voltage - Input (Min)：9V
• Voltage - Input (Max)：18V
• Voltage - Output 1：5V
• Voltage - Output 2：-5V
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：500mA, 500mA
• Power (Watts)：5 W
• Voltage - Isolation：2 kV
• Applications：ITE (Commercial)
• Features：SCP
• Operating Temperature：-40°C ~ 75°C
• Efficiency：81%
• Mounting Type：Through Hole
• Package / Case：24-DIP Module, 8 Leads
• Size / Dimension：1.26" L x 0.80" W x 0.40" H (32.0mm x 20.3mm x 10.2mm)
• Control Features：-

DC DC Converters datasheet and documents for REC5-1205DRW/H2/A
