Product Detailed Parameters
- Description：DIODE ARRAY GP 200V 3A TO-252GE
- Series：-
- Mfr：Rohm Semiconductor
- Package：Tape & Reel (TR),Cut Tape (CT)
- Diode Configuration：1 Pair Common Cathode
- Technology：Standard
- Voltage - DC Reverse (Vr) (Max)：200 V
- Current - Average Rectified (Io) (per Diode)：3A
- Voltage - Forward (Vf) (Max) @ If：930 mV @ 3 A
- Speed：Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr)：25 ns
- Current - Reverse Leakage @ Vr：10 µA @ 200 V
- Operating Temperature - Junction：150°C
- Mounting Type：Surface Mount
- Package / Case：TO-252-3, DPAK (2 Leads + Tab), SC-63
- Supplier Device Package：TO-252GE
- Grade：-
- Qualification：-
Download product information
Overview
The RF601BGE2DTL is a super fast recovery diode manufactured by Rohm Semiconductor. It features a common cathode configuration housed in a TO-252GE (D-Pak) surface-mount package. Key electrical specifications include a reverse voltage of 200V and an average rectified forward current of 6.0A. The device exhibits a maximum forward voltage of 0.93V at 3A and a maximum reverse current of 0.01mA at 200V. Its ultra-fast recovery time is 25ns, measured at 500mA with a reverse current of 1A.
Feature Summary
- Super fast recovery characteristics for high-speed switching applications
- Common cathode dual-diode configuration within a single package
- Surface mount design compatible with automated assembly processes
Applications
- General purpose rectification circuits
- High frequency switching power supplies
- DC-DC converter output stages
Procurement Notes
Verify the specific ordering suffix to ensure the correct tape-and-reel quantity of 2500 units per reel. Confirm RoHS compliance status and JEITA package code SC-63 alignment with your manufacturing requirements. Check for any automotive qualification restrictions if the end application involves vehicle electronics, as standard grades may not be suitable.
Selection Notes
Select this component when a 200V rating and 6A continuous current capacity are required in a compact D-Pak footprint. The 25ns reverse recovery time makes it suitable for higher frequency operations compared to standard recovery diodes. Ensure thermal management supports the power dissipation associated with the specified forward voltage drop under load conditions.
Part Context
This part belongs to Rohm's super fast recovery diode series, designed for efficient power conversion. It serves as a modernized replacement for older non-recommended variants like the RF601BM2D, offering improved packaging and reliability standards while maintaining similar pinout compatibility for existing designs requiring upgrade or migration.
Replacement Considerations
The RF601BGE2D is the lead-free equivalent without the tape-and-reel suffix. For direct substitution in existing assemblies, verify that the TO-252GE package dimensions match the PCB footprint intended for the original TO-252M variant.
