RFBPF2012080AM0T62

Overview

The RFBPF2012080AM0T62 is a band-pass RF filter manufactured by Walsin Technology Corporation. It operates with a center frequency of 2.45 GHz and features a bandwidth of 2 dB. The component is housed in a compact 0603 (1608 Metric) surface-mount package, designed for integration into radio frequency circuits requiring precise signal filtering.

Feature Summary

• Provides band-pass filtering functionality for radio frequency signals
• Engineered for operation at a 2.45 GHz center frequency
• Utilizes a compact 0603 surface-mount footprint for space-constrained designs

Applications

• Wireless communication systems operating in the 2.4 GHz ISM band
• Bluetooth device implementations
• Wi-Fi module signal conditioning

Procurement Notes

Verify the specific datasheet version to confirm electrical tolerances and thermal characteristics. Ensure the 0603 package dimensions align with the target PCB land pattern. Confirm RoHS compliance status if required by the end-product specifications. Cross-reference the manufacturer part number to avoid confusion with similar series components.

Selection Notes

Select this component when a narrow 2 dB bandwidth is required around 2.45 GHz. The 0603 size suits high-density board layouts. Evaluate insertion loss and rejection specs against system requirements. Consider thermal management capabilities during high-power RF transmission scenarios.

Part Context

This part belongs to the RFBPF series of RF filters from Walsin Technology Corporation. The series offers various center frequencies and bandwidths tailored for different wireless standards. The 0603 form factor represents a standard industry size for passive RF components, balancing performance with board space efficiency.

Replacement Considerations

Check for direct substitutes within the same Walsin RFBPF series that match the 2.45 GHz center frequency and 2 dB bandwidth. Verify pin compatibility and package dimensions before substitution. Consult official cross-reference lists for validated alternatives.
