RFECA3216060A1T

Antennas RF Overview

The RFECA3216060A1T is a surface-mount chip antenna manufactured by Walsin Technology Corporation. It operates within the 2.4GHz to 2.484GHz frequency range, supporting applications such as Bluetooth, WiFi, and Zigbee. The component features a gain of 2dBi and a maximum height of 0.60mm. Constructed using LTCC technology, it ensures high stability under temperature and humidity variations.

Antennas RF Feature Summary

• Utilizes LTCC process for enhanced environmental stability
• Compact surface-mount design suitable for miniaturization
• Optimized for 2.4GHz wireless communication protocols

Antennas RF Applications

• Bluetooth devices
• WiFi modules
• Zigbee networks
• WLAN equipment

Antennas RF Procurement Notes

Verify that the replacement part matches the original specifications regarding frequency range, gain, and physical dimensions. Confirm compatibility with the target PCB layout and soldering process. Ensure the substitute component meets the same RoHS compliance standards and moisture sensitivity level requirements as the original Walsin part.

Antennas RF Selection Notes

Select this component when space constraints require a low-profile antenna solution. The 0.60mm height facilitates integration into thin electronic enclosures. LTCC construction provides reliability in varying environmental conditions. Consider the 2dBi gain requirement for adequate signal coverage in compact wireless designs.

Antennas RF Part Context

This RF antenna belongs to Walsin's portfolio of passive components designed for modern electronics. It addresses the industry trend toward smaller form factors while maintaining performance integrity. The device supports various short-range wireless communication standards commonly found in consumer and industrial gadgets.

Antennas RF Replacement Considerations

CBR04C189B1GAC (KEMET) is listed as a parameter-equivalent alternative.
