RFPCA191515IMAB3G1

$2.26

Description：RF ANT 2.4GHZ PCB TRACE IPEX ADH
Series：-
Mfr：Walsin Technology Corporation
Package：Bulk

SKU:3a158efdaa1f Category: RF Antennas Brand: Walsin Technology Corporation

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

RFPCA191515IMAB3G1 is listed in the Antennas RF range at ChipApex. The manufacturer field lists Walsin Technology Corporation. Its product description is RF ANT 2.4GHZ PCB TRACE IPEX ADH. Review the specifications below when checking this part for your BOM.

Antennas RF specifications for RFPCA191515IMAB3G1

Description：RF ANT 2.4GHZ PCB TRACE IPEX ADH
Series：-
Mfr：Walsin Technology Corporation
Package：Bulk
RF Family/Standard：-
Frequency Group：UHF (2GHz ~ 3GHz)
Frequency (Center/Band)：2.4GHz
Frequency Range：-
Antenna Type：PCB Trace
Number of Bands：1
VSWR：-
Return Loss：-
Gain：-
Features：-
Termination：U.FL (UMCC), I-PEX MHF1
Ingress Protection：-
Grade：-
Qualification：-
Mounting Type：Adhesive
Height (Max)：-
Applications：-
Power - Max：-

Antennas RF datasheet and documents for RFPCA191515IMAB3G1

RFPCA191515IMAB3G1

Antennas RF Overview

The RFPCA191515IMAB3G1 is a PCB trace antenna manufactured by Walsin Technology Corporation, designed for operation in the 2.4 GHz and 2.5 GHz frequency bands. This component features an I-PEX MHF1 connector interface and utilizes adhesive mounting for secure attachment to printed circuit boards. It offers a gain of 4.53 dBi and includes a 50 mm cable length. The device complies with RoHS3 standards, ensuring environmental safety and regulatory adherence for electronic applications requiring reliable wireless connectivity.

Antennas RF Feature Summary

Integrated PCB trace design optimized for 2.4 GHz and 2.5 GHz wireless communication bands
Equipped with I-PEX MHF1 connector interface for standardized RF signal transmission
Adhesive mounting mechanism ensures stable physical attachment to circuit substrates

Antennas RF Applications

General RF antenna systems requiring 2.4 GHz connectivity
Wireless devices utilizing I-PEX MHF1 interfaces
Embedded electronics needing compact PCB trace solutions

Antennas RF Procurement Notes

Verify compliance with RoHS3 standards prior to integration. Confirm that the I-PEX MHF1 connector matches your system's RF interface requirements. Ensure the adhesive mounting method aligns with your assembly process capabilities. Check the 50 mm cable length against spatial constraints within the final enclosure design.

Antennas RF Selection Notes

Select this component when a low-profile PCB trace antenna is required for 2.4 GHz applications. Consider the adhesive mounting type if surface-mount assembly is preferred over through-hole methods. Verify compatibility with I-PEX MHF1 connectors used in your RF chain. Evaluate the 4.53 dBi gain against specific range and sensitivity requirements.

Antennas RF Part Context

This part belongs to the Walsin RFPCA series, which provides various RF antenna solutions. The series includes different models tailored for specific frequency bands and connector types. Walsin Technology Corporation specializes in passive components, including MLCC capacitors, resistors, and RF devices, offering a comprehensive portfolio for electronic manufacturing.
