RG1676-58

Overview

The Electrocube RG1676-58 is a first-order low-pass RC EMI filter designed for single-phase applications. It features a block configuration with four leads for panel mounting. The component integrates a 220 Ohm resistor and a 0.1 µF capacitor to suppress electromagnetic interference and contact arcing in heavy-duty environments.

Feature Summary

• Provides effective suppression of contact arcing and electrical noise
• Designed for heavy-duty applications requiring significant power handling
• Single-phase construction optimized for industrial equipment protection

Applications

• Industrial motor control circuits
• Heavy-duty switching equipment
• Electromagnetic interference filtering in power systems

Procurement Notes

Verify the specific suffix against manufacturer documentation to confirm exact resistance and capacitance values. Ensure the block package style matches the installation requirements. Confirm voltage ratings align with the operational environment to prevent component failure.

Selection Notes

Select this component when arc suppression and noise filtration are required for single-phase loads. The RC network topology offers a cost-effective solution for protecting sensitive electronics from transient voltage spikes generated by inductive loads.

Part Context

This model belongs to the RG1676 series of single-phase RC networks. These components are engineered to protect electronic equipment from costly failures caused by contact arcing and electrical noise common in industrial settings.

Replacement Considerations

Substitute only with verified RG1676 series variants having identical electrical parameters. Cross-referencing requires matching resistance, capacitance, and voltage ratings to ensure functional equivalence.
