RG1986-11

Overview

The Electrocube RG1986-11 is a single-phase RC network designed for arc suppression. It features a compact round shape with solid or stranded wire leads, typically 3 inches long and 18AWG gauge. The component operates within a temperature range of -40°C to +80°C. It is UL and ULC approved, ensuring compliance with safety standards for industrial applications.

Feature Summary

• Single-phase RC network configuration for effective arc suppression
• UL and ULC approved for industrial safety compliance
• Compact design allows free-hanging mounting across coils and contacts
• Available with solid or stranded wire leads for flexible installation

Applications

• Arc suppression across electrical coils
• Contact protection in switching circuits
• Industrial control panel integration
• Motor circuit noise reduction

Procurement Notes

Verify the specific capacitance and resistance values required for your application, as the RG1986 series includes variants with different ratings. Confirm lead type (solid vs. stranded) and length compatibility with your assembly process. Ensure the operating voltage rating meets or exceeds your circuit's maximum voltage to prevent failure. Check for UL/ULC certification requirements specific to your region or industry standard.

Selection Notes

Select the RG1986-11 based on its single-phase capability and compact form factor suitable for tight spaces. Consider the temperature range (-40°C to +80°C) to ensure reliability in your operating environment. Evaluate the lead configuration options to match your wiring harness or PCB layout needs. Verify that the component's voltage and current ratings align with the load characteristics it will protect.

Part Context

Electrocube is a recognized manufacturer of arc suppressing resistor-capacitor networks. The RG1986 series represents their line of single-phase RC networks, widely used in industrial automation and control systems. These components are engineered to extend contact life and reduce electromagnetic interference in AC circuits.

Replacement Considerations

Direct substitutes may include other Electrocube single-phase RC networks from the RG1986 or RG1784 series, provided electrical parameters match. Cross-brand replacements require careful verification of capacitance, resistance, voltage rating, and physical dimensions to ensure functional equivalence.
