Product Detailed Parameters
- Description：FILTER RC 100 OHMS/0.25UF TH
- Series：-
- Mfr：Electrocube
- Package：Bulk
- Type：Low Pass
- Filter Order：1st
- Technology：RC
- Number of Channels：1
- Center / Cutoff Frequency：-
- Attenuation Value：-
- Resistance - Channel (Ohms)：100
- Values：R = 100Ohms, C = 0.25µF
- ESD Protection：No
- Operating Temperature：-40°C ~ 80°C
- Applications：General Purpose
- Voltage - Rated：600V
- Mounting Type：Through Hole
- Package / Case：Radial
- Size / Dimension：1.000" L x 0.500" W (25.40mm x 12.70mm)
- Height：0.780" (19.81mm)
- Current：-
- Grade：-
- Qualification：-
Download product information
Overview
The Electrocube RG1988-6 is a single-phase RC network designed for power electronics applications. It features a capacitance of 0.25 microfarads with a tolerance of ±20%. The unit includes an integrated resistance of 150 ohms and is rated for a maximum voltage of 900V DC. The component utilizes MTW leads, facilitating free-hanging mounting across coils or contacts in aerospace and industrial environments.
Feature Summary
- Single-phase RC network configuration
- Compact design for free-hanging installation
- MTW leaded construction
Applications
- Aerospace power electronics
- Coil suppression circuits
- Contact protection networks
Procurement Notes
Verify the specific suffix (e.g., -6) to confirm resistance and voltage ratings, as the base series contains variants with different electrical parameters. Confirm lead type and mounting requirements against schematic specifications. Ensure environmental ratings meet operational standards. Cross-reference datasheet values directly with purchase orders to avoid substitution errors within the RG1988 family.
Selection Notes
Select this model when a 0.25 microfarad capacitance and 150 ohm resistance are required at 900V DC. Consider the compact form factor for space-constrained assemblies. Verify compatibility with existing coil or contact loads. Evaluate thermal performance if operating near maximum voltage limits. Compare against other single-phase networks if higher current handling is needed.
Part Context
Electrocube manufactures passive power electronics components for aerospace applications since 1961. The RG1988 series represents their range of single-phase RC networks. These components are engineered for reliability in demanding environments. The brand specializes in designs that support critical infrastructure and aviation systems through robust passive component solutions.
Replacement Considerations
Public confirmed substitute part numbers are not available in the provided documentation. Verify exact electrical matches before considering alternative manufacturers. Check physical dimensions and lead configurations for mechanical compatibility. Ensure voltage and capacitance tolerances align with original design requirements.
