RG2030-3

$36.29

Description：FILTER RC 47OHM/1UF THROUGH HOLE
Series：-
Mfr：Electrocube
Package：Bulk

SKU:4252eb836f5b Category: EMI/RFI Filters (LC, RC Networks) Brand: Electrocube

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：FILTER RC 47OHM/1UF THROUGH HOLE
Series：-
Mfr：Electrocube
Package：Bulk
Type：Low Pass
Filter Order：1st
Technology：RC
Number of Channels：1
Center / Cutoff Frequency：-
Attenuation Value：-
Resistance - Channel (Ohms)：47
Values：R = 47Ohm, C = 1µF
ESD Protection：No
Operating Temperature：-40°C ~ 80°C
Applications：General Purpose
Voltage - Rated：200V
Mounting Type：Through Hole
Package / Case：Radial
Size / Dimension：1.000" L x 0.500" W (25.40mm x 12.70mm)
Height：0.780" (19.81mm)
Current：-
Grade：-
Qualification：-

Download product information

RG2030-3

Overview

The Electrocube RG2030-3 is a single-phase RC network designed for through-hole mounting. It features a capacitance of 1.0 µF with ±10% tolerance and a series resistance of 68 Ohms at ±10%. The component is rated for 300V DC. Physical dimensions are 1.000 inches in length, 0.500 inches in width, and 0.75 inches in height (25.40mm x 12.70mm x 19.05mm). It utilizes radial leads for circuit integration.

Feature Summary

Constructs a series resistor-capacitor network for EMI/RFI suppression
Designed for free-hanging mounting across coils and contacts
Utilizes stranded wire leads for reliable through-hole connection

Applications

General purpose EMI filtering
Surge suppression across contactors
Arc suppression for relay coils

Procurement Notes

Verify the specific voltage rating and tolerance requirements against the application datasheet. Confirm that the radial lead pitch matches the PCB layout or terminal spacing. Ensure the 300V DC rating exceeds the peak transient voltages present in the target circuit to prevent dielectric breakdown.

Selection Notes

Select this component when a compact, single-phase RC snubber is required for AC or DC coil protection. The 68 Ohm resistance value provides specific damping characteristics suitable for general-purpose switching applications. Consider the physical size constraints as the unit measures 1.000 inch in length.

Part Context

This part belongs to the Electrocube RG2030 series of MTW leaded single-phase RC networks. These components are engineered for compact installation in industrial control panels. The series offers various capacitance and resistance combinations to address different inductive load requirements.

Replacement Considerations

Cross-reference with other single-phase RC networks offering 1.0 µF capacitance and approximately 68 Ohms resistance at 300V. Verify lead configuration and dimensional compatibility before substitution.
