RG2031-1

Overview

The Electrocube RG2031-1 is a single-phase RC network designed for noise suppression applications. It features a capacitance of 0.1 MFD with a tolerance of ±20% and a resistance of 22 Ohms. The component is rated for 900V DC and operates within a temperature range of -40°C to +80°C. It includes 9-inch #18AWG MTW leads for connection.

Feature Summary

• Single-phase RC network configuration
• Integrated noise suppression capability
• Fixed lead length termination

Applications

• Noise suppression in electrical circuits
• Industrial control systems
• Power supply filtering

Procurement Notes

Verify the specific suffix (e.g., -1, -1-9) against the datasheet to confirm lead length and voltage rating. Ensure the 900V DC rating meets system requirements. Confirm RoHS compliance status if required by assembly specifications.

Selection Notes

Select this model when a fixed 0.1 MFD capacitor and 22 Ohm resistor are needed in a single package. Consider the 9-inch lead length for board spacing. Verify that the 900V DC rating exceeds the peak circuit voltage.

Part Context

Part of the Electrocube RG2031 series of RC networks. Variants differ by resistance value, lead length, and voltage rating. Commonly used in industrial environments requiring robust passive components.

Replacement Considerations

Check equivalent RC networks from other manufacturers with matching 0.1 MFD capacitance and 22 Ohm resistance. Verify voltage ratings and physical dimensions for compatibility.

FAQ

What is the resistance value of the RG2031-1?

The resistance value is 22 Ohms.

What is the maximum voltage rating?

The component is rated for 900V DC.
