Product Detailed Parameters
- Description：FILTER RC 220OHM/0.1UF TH
- Series：-
- Mfr：Electrocube
- Package：Bulk
- Type：Low Pass
- Filter Order：1st
- Technology：RC
- Number of Channels：1
- Center / Cutoff Frequency：-
- Attenuation Value：-
- Resistance - Channel (Ohms)：220
- Values：R = 220Ohm, C = 0.1µF
- ESD Protection：No
- Operating Temperature：-40°C ~ 80°C
- Applications：General Purpose
- Voltage - Rated：200V
- Mounting Type：Through Hole
- Package / Case：Radial
- Size / Dimension：1.000" L x 0.380" W (25.40mm x 9.65mm)
- Height：0.660" (16.76mm)
- Current：-
- Grade：-
- Qualification：-
Download product information
Overview
The Electrocube RG2031-8 is a single-phase RC network arc suppressor designed for noise suppression and contact protection. It features a capacitance of 0.1 µF with a tolerance of ±20% and a resistance of 330 Ohms with a tolerance of 10%. The component is rated for a maximum voltage of 900 VDC and has a power rating of 0.5 Watts. It utilizes 18 AWG leads, typically 8 inches in length, allowing for free-hanging installation across coils or contacts.
Feature Summary
- Single-phase RC network configuration for effective arc suppression
- Compact design suitable for free-hanging mounting applications
- High voltage rating of 900 VDC for robust circuit protection
Applications
- Suppressing arcs across electrical contacts
- Noise suppression in single-phase circuits
- Protection of electromagnetic coils
Procurement Notes
Verify the specific resistance value against application requirements, as datasheets may list variations such as 330 Ohms or 220 Ohms for similar part numbers. Confirm lead length and gauge specifications to ensure compatibility with existing wiring harnesses. Ensure the 900 VDC rating meets the system's peak voltage demands.
Selection Notes
Select this component when a single-phase RC snubber is required for high-voltage DC applications up to 900V. The 0.1 µF capacitance and specific resistance value are critical for damping oscillations. Consider the physical dimensions and lead length for mounting constraints in tight spaces.
Part Context
The RG2031 series consists of MTW leaded single-phase RC networks manufactured by Electrocube. These components are engineered for compact size and ease of installation. They are commonly used in industrial control panels and motor control circuits to extend the life of switching devices by reducing electrical stress.
Replacement Considerations
Cross-reference with RG2031-9 (470 Ohm) or RG2031-3 (47 Ohm) if different resistance values are needed. Verify that substitute parts maintain the same 0.1 µF capacitance and 900 VDC rating to ensure equivalent performance.
