RL-4400-2-26,0

$2.30

Description：CMC 26MH 500MA 2LN THROUGH HOLE
Series：-
Mfr：Renco Electronics, Inc.
Package：Bulk

SKU:81638a54bf49 Category: Common Mode Chokes Brand: Renco Electronics, Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

RL-4400-2-26,0 is listed in the Common Mode Chokes range at ChipApex. The manufacturer field lists Renco Electronics, Inc.. Its product description is CMC 26MH 500MA 2LN THROUGH HOLE. Review the specifications below when checking this part for your BOM.

Common Mode Chokes specifications for RL-4400-2-26,0

Description：CMC 26MH 500MA 2LN THROUGH HOLE
Series：-
Mfr：Renco Electronics, Inc.
Package：Bulk
Filter Type：Power Line
Number of Lines：2
Current Rating (Max)：500mA
DC Resistance (DCR) (Max)：1.8Ohm
Voltage Rating - DC：250V
Voltage Rating - AC：-
Operating Temperature：-55°C ~ 130°C
Ratings：-
Approval Agency：-
Features：-
Mounting Type：Through Hole
Size / Dimension：0.752" L x 0.650" W (19.10mm x 16.50mm)
Height (Max)：0.850" (21.60mm)
Package / Case：Vertical, 4 PC Pin
Inductance @ Frequency：26 mH @ 10 kHz

Common Mode Chokes datasheet and documents for RL-4400-2-26,0

RL-4400-2-26,0

Common Mode Chokes Overview

The RL-4400-2-26,0 is a two-line common mode choke manufactured by Renco Electronics Inc. It features a nominal inductance of 26 mH measured at 10 kHz and supports a maximum rated current of 500 mA. The component has a maximum DC resistance of 1.8 ohms and a nominal voltage rating of 250 V DC. It utilizes a through-hole mounting style with a tubular package configuration. The device operates within a temperature range of -40°C to +130°C and complies with RoHS 3 standards.

Common Mode Chokes Feature Summary

Provides common mode noise suppression for two-line circuits
Utilizes a through-hole tubular package for board mounting
Complies with RoHS 3 environmental regulations

Common Mode Chokes Applications

Two-line power supply filtering
Common mode noise reduction in electronic circuits
Signal integrity protection in low-voltage DC systems

Common Mode Chokes Procurement Notes

Verify the specific suffix designation matches the required inductance and current ratings for your design. Confirm that the through-hole footprint dimensions align with your PCB layout constraints. Ensure the operating temperature range meets the environmental requirements of the final assembly. Check for RoHS 3 compliance if required by regional regulations.

Common Mode Chokes Selection Notes

Select this component when a 26 mH inductance value is required for common mode interference suppression in two-wire configurations. Consider the 500 mA current limit and 1.8 ohm DC resistance for power loss calculations. Evaluate the physical size against available board space for through-hole implementation. Verify compatibility with the system's voltage and thermal operating conditions.

Common Mode Chokes Part Context

This part belongs to the RL-4400 series of common mode chokes produced by Renco Electronics Inc. The series offers various inductance values and current ratings tailored for different filtering applications. The RL-4400-2-26,0 specifically denotes a two-line configuration with 26 mH inductance. These components are designed for general-purpose electromagnetic interference suppression in electronic assemblies.
