RL-7500-4-680M

Fixed Inductors Overview

The RL-7500-4-680M is a fixed inductor manufactured by Renco Electronics, Inc. It features a shielded drum core and wirewound construction designed for surface mount applications. The component provides an inductance of 68 µH with a tolerance of ±20%. It supports a maximum current rating of 3.2 A and exhibits a maximum DC resistance of 73 mΩ. The inductance is measured at a frequency of 100 kHz.

Fixed Inductors Feature Summary

• Shielded drum core design
• Wirewound construction
• Surface mount package

Fixed Inductors Applications

• General electronic circuits requiring fixed inductance
• Power supply filtering applications
• Signal processing components

Fixed Inductors Procurement Notes

Verify the manufacturer part number RL-7500-4-680M against official Renco Electronics documentation to confirm specifications. Ensure compatibility with surface mount assembly processes. Check for any specific handling requirements related to the shielded drum core construction before procurement.

Fixed Inductors Selection Notes

Select this component when a 68 µH inductance value is required for surface mount designs. Consider the 3.2 A current rating and 73 mΩ resistance for power handling needs. Verify that the shielded drum core form factor fits within the available PCB space constraints.

Fixed Inductors Part Context

This component belongs to the RL-7500 series of fixed inductors from Renco Electronics. The series offers various inductance values and current ratings in a consistent surface mount footprint. The model designation indicates specific electrical characteristics within this product line.

Fixed Inductors Replacement Considerations

Consult official Renco Electronics substitution guides for verified alternative part numbers. Do not assume cross-compatibility with generic inductors without verifying electrical parameters and physical dimensions.
