RM 048L-N

RM 048L-N is listed in the Power Relays, Over 2 Amps range at ChipApex. The manufacturer field lists Tele Haase. Its product description is RELAY GEN PURPOSE 4PDT 7A 48V. Review the specifications below when checking this part for your BOM.

Power Relays, Over 2 Amps specifications for RM 048L-N

• Description：RELAY GEN PURPOSE 4PDT 7A 48V
• Series：RM
• Mfr：Tele Haase
• Package：Box
• Mounting Type：Socketable
• Coil Voltage：48VDC
• Contact Form：4PDT (4 Form C)
• Contact Rating (Current)：7:00 AM
• Switching Voltage：250VAC, 24VDC - Max
• Load - Max Switching：-
• Coil Current：18.5 mA
• Coil Type：Non Latching
• Features：Lighted Indicator, Mechanical Indicator, Test Button
• Termination Style：Plug In
• Seal Rating：-
• Coil Insulation：-
• Must Operate Voltage：38.4 VDC
• Must Release Voltage：4.8 VDC
• Operating Temperature：-40°C ~ 70°C
• Contact Material：Silver Nickel (AgNi)
• Approval Agency：-
• Relay Type：General Purpose
• Grade：-
• Qualification：-
• Operate Time：13 ms
• Release Time：3 ms

Power Relays, Over 2 Amps datasheet and documents for RM 048L-N
