RNA3048B-16.6666M

Overview

The RNA3048B-16.6666M is a standard crystal oscillator (XO) manufactured by NDK. It operates at a frequency of 16.6666 MHz and utilizes CMOS output logic. The device supports a supply voltage of 1.8V and features a standby function for power management. It is housed in a compact 4-SMD, no-lead package with dimensions of 2.50mm x 2.00mm and a maximum seated height of 0.90mm. The component complies with RoHS standards and draws a maximum supply current of 20µA in the disabled state.

Feature Summary

• CMOS output interface for digital signal compatibility
• Integrated standby mode to minimize power consumption
• Compact surface-mount design suitable for space-constrained applications

Applications

• Consumer electronics requiring low-power clock signals
• Portable devices utilizing 1.8V logic systems
• Embedded systems needing precise timing references

Procurement Notes

Verify that the specific order suffix matches the required frequency tolerance and stability specifications. Confirm the package variant aligns with the PCB footprint requirements. Ensure the operating temperature range meets the environmental conditions of the target application. Check for any specific handling instructions regarding electrostatic discharge during assembly.

Selection Notes

Select this component when a 1.8V supply voltage is available and CMOS output levels are required. Consider the 16.6666 MHz frequency for specific data rate synchronization needs. Evaluate the small form factor against board space limitations. Compare power consumption metrics if battery life is a critical design constraint.

Part Context

This oscillator belongs to NDK's RNA series, designed for general-purpose timing applications. The series offers various frequencies and packages to support diverse electronic designs. The RNA3048B variant specifically targets compact, low-voltage environments common in modern portable technology.

Replacement Considerations

Consult official cross-reference lists for compatible alternatives. Verify pinout compatibility and electrical parameters before substitution. Ensure replacement parts meet the same RoHS compliance and package dimensions.
