RNF12JBD620R

Overview

The RNF12JBD620R is a metal film MELF resistor manufactured by SEI Stackpole. It features a resistance value of 620 Ohms with a tolerance of ±5%. The component has a power rating of 0.125W (1/8W) and operates within a temperature range of -55°C to +155°C. It exhibits a temperature coefficient of 100 ppm/°C and supports a maximum working voltage of 150V. The package dimensions are 2.2mm in length and 1.1mm in diameter, suitable for PCB mount applications.

Feature Summary

• Constructed using metal film technology for stable performance
• Designed for surface mount PCB integration
• Capable of operation across extended industrial temperature ranges

Applications

• General purpose electronic circuitry
• Industrial control systems
• Consumer electronics assemblies

Procurement Notes

Verify the specific suffix configuration against official datasheets to ensure correct tolerance and packaging specifications. Confirm RoHS compliance status and availability constraints directly with authorized distributors prior to ordering. Cross-reference manufacturer part numbers to avoid substitution errors during procurement processes.

Selection Notes

Select this component when space-constrained surface mount designs require precise resistance values. Consider its low power rating and voltage limits relative to circuit requirements. Evaluate thermal management needs given the small physical footprint and operating temperature specifications.

Part Context

This part belongs to the MLF series of MELF resistors from SEI Stackpole. These components provide an alternative to traditional axial leads in compact printed circuit board layouts. The series offers reliable performance for general electronic applications requiring standardized resistance values.

Replacement Considerations

MLF18JTD620R
