RNF18JBD10R0

Overview

The RNF18JBD10R0 is a fixed axial leaded resistor manufactured by Stackpole Electronics Inc. It belongs to the RNF series and utilizes metal film technology for stable performance. The component features a resistance value of 10 ohms with a tolerance of ±5%. It has a power rating of 0.125W (1/8W) and operates within a temperature range of -55°C to +155°C. The temperature coefficient is ±100ppm/°C, and it supports a maximum working voltage of 200V. The physical dimensions are 1.80mm in diameter and 3.30mm in length.

Feature Summary

• Constructed with metal film composition for precision and stability.
• Features flame retardant coating and safety design characteristics.
• Supports through-hole mounting with axial leads for PCB integration.

Applications

• General purpose electronic circuits
• Signal conditioning networks
• Current sensing applications

Procurement Notes

Verify the specific suffix 'JBD' against official Stackpole documentation to confirm the exact tolerance and packaging configuration. Ensure the requested quantity matches the manufacturer's standard packing specifications. Confirm RoHS compliance status for the specific production batch prior to final procurement authorization.

Selection Notes

Select this component when a low-resistance value with moderate tolerance is required for general-purpose applications. The 1/8W power rating suits low-current signal paths rather than high-power load handling. Consider the ±100ppm/°C temperature coefficient for thermal stability requirements in the target operating environment.

Part Context

This part is part of the RNF series of metal film resistors from Stackpole Electronics. The series offers various resistance values and tolerances. The RNF18 designation indicates the 1/8W power rating and axial package style common in this product line.

Replacement Considerations

Direct substitutes must match the 10 ohm resistance, ±5% tolerance, 1/8W power rating, and axial package. Verify that alternative manufacturers offer compatible temperature coefficients and voltage ratings for equivalent performance.
