RNF18JBD3K30

Overview

The RNF18JBD3K30 is a metal film through-hole resistor manufactured by Stackpole Electronics Inc. It features a resistance of 3.3 kOhms with a tolerance of ±5% and a power rating of 125 mW (1/8 W). The component operates within a temperature range of -55°C to +155°C and has a temperature coefficient of 100 PPM/°C. Rated for 200 V, it utilizes an axial leaded package measuring 1.8 mm in diameter and 3.3 mm in length.

Feature Summary

• Constructed using metal film technology for stable performance
• Features a precision resistor design suitable for general-purpose applications
• Compliant with RoHS standards

Applications

• General purpose electronic circuits
• PCB mount installations
• Precision resistor networks

Procurement Notes

Verify the specific suffix 'BD' against official datasheets to confirm bulk packaging status versus reel options. Confirm that the 3.3 kOhm value aligns with circuit requirements. Check for any regional distribution restrictions or specific handling guidelines provided by SEI Stackpole prior to ordering.

Selection Notes

Select this component when a standard 5% tolerance metal film resistor is required for axial mounting. Ensure the 125 mW power rating and 200 V voltage limit are sufficient for the target application environment. Consider the 100 PPM/°C temperature coefficient for thermal stability needs.

Part Context

This part belongs to the RNF series of precision resistors from SEI Stackpole. It is categorized under metal film through-hole resistors. The product line emphasizes precision characteristics and compliance with environmental regulations such as RoHS and REACH.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation.
