RP115-6-2.2-W

Overview

The Astrodyne TDI RP115-6-2.2-W is a compact, single-phase, single-stage power line filter designed for chassis mounting. It features quick disconnect terminals and operates at 50 Hz or 60 Hz with a voltage rating of 250 VAC. The unit handles a current rating of 6 A and includes a capacitance of 2.2 nF (2200 pF). It complies with UL, CSA, and EN standards.

Feature Summary

• Compact single-stage EMI filtering architecture
• Quick disconnect terminal connections
• Chassis mount installation style

Applications

• Industrial equipment power conditioning
• Medical device power supplies
• Commercial electronics protection

Procurement Notes

Verify the specific suffix 'W' against official datasheets to confirm terminal configuration and compliance certifications. Ensure the 2.2 nF capacitance aligns with leakage current requirements for your application. Confirm chassis mounting dimensions and quick connect tab specifications before integration.

Selection Notes

Select this component when a low-profile, single-phase filter is required for 6 A circuits. The quick disconnect feature facilitates rapid assembly and maintenance. Verify that the 250 VAC rating meets system voltage needs and that the 2.2 nF capacitance provides sufficient attenuation without exceeding leakage limits.

Part Context

This model belongs to the RP115 series, which offers compact EMI solutions. It shares the series' single-stage design philosophy but differs in current handling and capacitance values compared to other variants like the RP115-20 series. The 'W' suffix typically denotes specific terminal or packaging variations within the product line.

Replacement Considerations

Check for direct substitutes within the RP115 series with matching 6 A ratings and 2.2 nF capacitance. Verify that alternative models maintain compatible quick disconnect terminal types and chassis mounting footprints to ensure mechanical interchangeability.
