RP190-3-3.3

Overview

The RP190-3-3.3 is a single-stage, one-phase power line filter manufactured by Astrodyne TDI. It features a compact PCB mount design with solder termination and a rated current of 3 A at 250 VAC. The unit incorporates a 3.3 nF capacitance value and operates within a temperature range of -25 C to +40 C. Compliance certifications include cURus and EN133200 standards.

Feature Summary

• Compact printed circuit board mounting configuration
• Single-stage electromagnetic interference filtering architecture
• Solder-based electrical termination method

Applications

• Electronic equipment requiring compact EMI suppression
• Power supply input stages for low-current applications
• Industrial control systems with limited board space

Procurement Notes

Verify the specific suffix designation against official manufacturer documentation to confirm exact terminal type and certification status. Confirm that the component meets all applicable regional safety regulations for the intended end-use environment before finalizing procurement decisions.

Selection Notes

Select this component when a single-stage solution is sufficient for the required attenuation levels. Ensure the available printed circuit board area accommodates the physical dimensions and that the soldering process aligns with the specified thermal characteristics of the device.

Part Context

This model belongs to the RP190 series, which focuses on providing efficient noise reduction in space-constrained environments. The series utilizes standardized construction methods to ensure reliable performance across various industrial and commercial electronic applications requiring basic power line conditioning.

Replacement Considerations

Consult official substitution guides for compatible alternatives. Verify that any replacement part maintains identical voltage ratings, current capacity, and termination style to ensure proper integration without modifying existing circuit layouts.
