RP2180-3-0-QD

Overview

The RP2180-3-0-QD is a single-phase, single-stage power line filter from the Astrodyne TDI RP2180 series. It features a 3 A current rating and a 250 VAC voltage rating for operation at 50/60 Hz. The component utilizes quick connect terminals and chassis mount installation. Key electrical specifications include a capacitance of 0 nF and compliance with UL, CSA, and EN standards.

Feature Summary

• Ultra compact single-stage design
• High-performance EMI filtering
• Quick connect termination

Applications

• Compact electronic equipment requiring space-saving filters
• Single-phase AC power line noise suppression
• Chassis-mounted industrial control systems

Procurement Notes

Verify the specific datasheet version for the RP2180-3-0-QD to confirm exact physical dimensions and terminal configurations. Ensure compatibility with the target chassis mounting holes and wire gauge requirements for the quick connect terminals before finalizing procurement.

Selection Notes

Select this model for applications requiring a minimal footprint single-stage filter with a 3 A capacity. Confirm that the 0 nF capacitance meets the leakage current constraints of the system. Verify that the 250 VAC rating aligns with the local mains voltage supply.

Part Context

This component belongs to the RP2180 series, which is characterized by ultra-compact form factors designed for high-density packaging. The series provides single-stage filtering solutions for single-phase AC lines, balancing performance with size constraints in modern electronic enclosures.

Replacement Considerations

Consult official substitution guides for equivalent single-stage filters within the same current and voltage ratings. Verify mechanical fitment and terminal type compatibility when considering alternative part numbers from the manufacturer or other vendors.
