Product Detailed Parameters
- Description：LINE FILTER 250VAC 30A CHASS MNT
- Series：RP230
- Mfr：Astrodyne TDI
- Package：Box
- Filter Type：Single Phase
- Configuration：Two Stage
- Voltage - Rated DC：-
- Voltage - Rated AC：250V
- Current：30 A
- Frequency - Operating：50/60Hz
- Applications：General Purpose
- Approval Agency：CE, cURus, SEMKO
- Operating Temperature：-25°C ~ 100°C
- Mounting Type：Chassis Mount
- Termination Style：Threaded Post (M4)
- Inductance：-
- Voltage - Rated AC (Phase to Ground/Neutral)：-
Download product information
Overview
The RP230-30-4.7-S is a high-performance, single-phase, two-stage power line filter manufactured by Astrodyne TDI. It features a capacitance of 4.7 nF and supports a continuous current rating of 30 A at a voltage rating of 250 VAC. Designed for chassis mounting with stud termination, the unit operates within a temperature range of -25°C to +40°C. It complies with UL, CSA, and EN standards and exhibits a leakage current of 400 µA at 50/60 Hz.
Feature Summary
- Dual-stage filtering architecture for enhanced noise attenuation
- Integrated thermal protection via built-in circuit breaker
- Robust chassis-mount construction with stud terminals
Applications
- Industrial motor drives and servo systems
- Medical imaging equipment requiring low leakage current
- High-density electronic test and measurement instruments
Procurement Notes
Verify the specific suffix against official datasheets to confirm terminal configuration and certification requirements. Ensure the selected variant matches the required voltage and current ratings for the target application. Cross-reference compliance marks such as UL or EN with local regulatory needs before finalizing procurement orders.
Selection Notes
Select this model when high attenuation in a compact form factor is required for 30 A circuits. The dual-stage design offers superior performance compared to single-stage alternatives. Verify that the chassis mounting style and stud termination are compatible with the available installation space and wiring infrastructure.
Part Context
This component belongs to the RP230 series, which focuses on high-performance EMI suppression for demanding industrial environments. The series provides various current ratings while maintaining consistent physical dimensions and mounting styles for system integration flexibility.
Replacement Considerations
Direct substitutes include other RP230 series variants with adjusted current ratings, such as the RP230-15-4.7-S or RP230-60-4.7-S, provided electrical parameters align with the system requirements.
