RP692-75-100-W

Power Line Filter Modules Overview

The RP692-75-100-W is a high-voltage, high-current DC power line filter from the Astrodyne TDI RP428 series. It features a chassis mount design with stud termination for secure installation. The unit is rated for 75A continuous current and supports voltages up to 1.2kVAC. It includes a capacitance of 100nF and operates within a temperature range of -25°C to 100°C.

Power Line Filter Modules Feature Summary

• Designed for high voltage and high current DC applications
• Chassis mount construction with stud termination
• Capable of handling 75A continuous current loads

Power Line Filter Modules Applications

• High voltage DC power systems
• Industrial power conditioning equipment
• Medical imaging power supplies

Power Line Filter Modules Procurement Notes

Verify exact lead times and availability directly with authorized distributors or the manufacturer, as stock levels fluctuate. Confirm that the specific suffix 'W' matches your required configuration, as ordering suffixes may denote variations in packaging or minor specifications without changing core function. Ensure compatibility with existing chassis mounting hardware.

Power Line Filter Modules Selection Notes

Select this component when high voltage isolation and significant current capacity are required in a compact chassis-mount form factor. The 100nF capacitance provides effective filtering for specific noise profiles. Verify that the stud termination method aligns with your assembly process and that the operating temperature range meets environmental requirements.

Power Line Filter Modules Part Context

This model belongs to the RP428 series of power line filters manufactured by Astrodyne TDI. The series is specialized for demanding industrial and medical applications requiring robust EMI suppression in high-power DC circuits. The RP692 designation indicates specific performance characteristics within this high-voltage family.

Power Line Filter Modules Replacement Considerations

Check for direct substitutes within the RP692 series with different current or capacitance ratings if system parameters change. Ensure any replacement maintains the same chassis mount style and stud termination dimensions to fit existing enclosures without modification.
