RS2BE-06-G-SMT

Headers, Receptacles, Female Sockets Overview

The Adam Tech RS2BE-06-G-SMT is a board-to-board connector designed for surface mount technology applications. It features a dual-row configuration with six positions per row, providing a total of twelve contacts. The connector utilizes a 1.27mm (0.050 inch) pitch to facilitate dense circuit board layouts. Contact surfaces are finished with gold plating over nickel to ensure reliable signal transmission and corrosion resistance. The housing is constructed from thermoplastic material rated UL94 V-0 for flammability. This component supports vertical mounting orientation and includes locking features to secure mating connections.

Headers, Receptacles, Female Sockets Feature Summary

• Dual-row surface mount architecture for high-density interconnects
• Gold-plated contact surfaces for enhanced conductivity and durability
• UL94 V-0 rated thermoplastic insulation for fire safety compliance
• Integrated locking mechanism to maintain secure mating engagement

Headers, Receptacles, Female Sockets Applications

• High-density electronic module interconnections
• Industrial control system board assemblies
• Telecommunications equipment internal connections
• Automotive electronics sub-system integration

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific ordering suffix against the manufacturer's current datasheet to confirm exact pin count, plating thickness, and packaging type. Ensure the selected variant matches the required board thickness and mating height specifications for the target application. Confirm RoHS3 compliance status if environmental regulations apply to the end product.

Headers, Receptacles, Female Sockets Selection Notes

Select this connector when space constraints require a compact dual-row interface with a standard 1.27mm pitch. Evaluate the mechanical retention strength provided by the surface mount termination style against vibration requirements. Consider the thermal management capabilities of the gold-plated contacts if operating in environments with elevated temperatures or high current loads.

Headers, Receptacles, Female Sockets Part Context

This component belongs to the broader family of board-to-board connectors manufactured by Adam Tech. It serves as a critical interconnection element within multi-layer PCB designs, enabling vertical stacking or parallel board arrangements. The design prioritizes signal integrity and mechanical stability in confined spaces typical of modern consumer and industrial electronics.

Headers, Receptacles, Female Sockets Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Verify compatibility with mating headers from other manufacturers based on pitch, row count, and housing dimensions before substitution.
