RS3K-0505S/H3

RS3K-0505S/H3 is listed in the DC DC Converters range at ChipApex. The manufacturer field lists Recom Power. Its product description is 3W DC/DC-CONVERTER 'ECONOLINE' S. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for RS3K-0505S/H3

• Description：3W DC/DC-CONVERTER 'ECONOLINE' S
• Series：ECONOLINE RS3K-Z (3W)
• Mfr：Recom Power
• Package：Tube
• Type：Isolated Module
• Number of Outputs：1
• Voltage - Input (Min)：4.5V
• Voltage - Input (Max)：9V
• Voltage - Output 1：5V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：600mA
• Power (Watts)：3 W
• Voltage - Isolation：3 kV
• Applications：ITE (Commercial)
• Features：Remote On/Off
• Operating Temperature：-40°C ~ 105°C (With Derating)
• Efficiency：74%
• Mounting Type：Through Hole
• Package / Case：8-SIP Module, 7 Leads
• Size / Dimension：0.86" L x 0.36" W x 0.44" H (21.8mm x 9.2mm x 11.1mm)
• Supplier Device Package：8-SIP
• Control Features：Enable, Active High
• Approval Agency：cURus
• Standard Number：62368-1
• Grade：-
• Qualification：-
