RS514-0.5-02

$2.95

Description：CMC 480UH 500MA 2LN TH
Series：RS
Mfr：Schaffner EMC Inc.
Package：Tray

SKU:5f5325c2a55c Category: Common Mode Chokes Brand: Schaffner EMC Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：CMC 480UH 500MA 2LN TH
Series：RS
Mfr：Schaffner EMC Inc.
Package：Tray
Filter Type：Signal Line
Number of Lines：2
Current Rating (Max)：500mA (Typ)
DC Resistance (DCR) (Max)：800mOhm (Typ)
Voltage Rating - DC：-
Voltage Rating - AC：250V
Operating Temperature：-40°C ~ 125°C
Ratings：-
Approval Agency：UR, VDE
Features：-
Mounting Type：Through Hole
Size / Dimension：0.886" L x 0.846" W (22.50mm x 21.50mm)
Height (Max)：0.520" (13.20mm)
Package / Case：Horizontal, 4 PC Pin
Inductance @ Frequency：480 µH @ 1 kHz
Qualification：-
Grade：-

Download product information

RS514-0.5-02

Overview

The Schaffner RS514-0.5-02 is a common mode choke designed for electromagnetic interference suppression in single-phase circuits. It features a rated current of 500 mA and an inductance value of 480 uH. The component supports through-hole mounting with PC pin termination, ensuring secure connection on printed circuit boards. It operates within a temperature range of -25°C to 100°C and is suitable for frequencies up to 400 Hz. The device complies with RoHS3 standards and holds CSA, ENEC, and UR certifications.

Feature Summary

Provides effective common mode noise attenuation for sensitive electronic loads
Supports reliable through-hole integration via standard PC pin termination
Operates effectively across a wide thermal range from -25°C to 100°C

Applications

Single-phase power line filtering
Electromagnetic compatibility enhancement in consumer electronics
Industrial control system signal protection

Procurement Notes

Verify the specific suffix codes against official datasheets to ensure correct inductance and current ratings. Confirm that the through-hole package dimensions match the target PCB layout. Check for recent product change notifications regarding marking or material composition updates. Ensure compliance with local safety certification requirements such as UL or ENEC before finalizing procurement.

Selection Notes

Select this component when designing single-phase circuits requiring moderate common mode noise suppression. The 480 uH inductance offers a balance between impedance and current handling for 500 mA applications. Consider the operating temperature range and physical size constraints during the initial design phase. Verify that the PC pin spacing aligns with existing board footprints to avoid redesign efforts.

Part Context

The RS514 series represents Schaffner's lineup of common mode chokes intended for general-purpose EMC applications. This specific model falls under the broader category of passive components used for noise reduction. It complements other Schaffner filters by providing targeted interference mitigation in compact form factors suitable for space-constrained electronic assemblies.
