RS622-4-02

Overview

The RS622-4-02 is a vertical differential mode choke manufactured by Schaffner EMC Inc. It features a nominal inductance of 15 µH and a current rating of 4 A. The component utilizes through-hole mounting technology for circuit board integration.

Feature Summary

• Vertical leaded construction for printed circuit board mounting
• Differential mode filtering capability
• Through-hole termination style

Applications

• General electronic equipment noise suppression
• Power supply input filtering
• Signal line interference reduction

Procurement Notes

Verify the manufacturer designation as Schaffner EMC Inc. Confirm the part number RS622-4-02 matches the required 15 µH inductance and 4 A current specifications. Ensure the vertical through-hole package type aligns with the target PCB layout requirements before procurement.

Selection Notes

Select this component when vertical orientation is required for space-constrained PCB designs. The 4 A rating suits moderate current applications, while the 15 µH value targets specific differential noise frequencies. Verify thermal performance under continuous load conditions.

Part Context

This component belongs to the Schaffner EMC Inc. common mode and differential mode choke series. It serves as an electromagnetic interference suppression element within power and signal circuits, complementing other passive filter components in the manufacturer's portfolio.

Replacement Considerations

Cross-reference with RS622-2-02 for similar form factor applications. Verify that substitute parts maintain identical 15 µH inductance and 4 A current handling capabilities to ensure circuit compatibility.
