RSF-2380.000-20000-3030-TR

$11.04

Description：FILTER SAW 2.38GHZ 5SMD
Series：RSF
Mfr：Raltron Electronics
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:8cb443e1a84a Category: SAW Filters Brand: Raltron Electronics

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：FILTER SAW 2.38GHZ 5SMD
Series：RSF
Mfr：Raltron Electronics
Package：Tape & Reel (TR),Cut Tape (CT)
Frequency - Center：2.38GHz
Bandwidth：20MHz
Insertion Loss：2.4dB
Ratings：-
Applications：-
Mounting Type：Surface Mount
Package / Case：6-SMD, No Lead
Height (Max)：0.058" (1.48mm)
Size / Dimension：0.118" L x 0.118" W (3.00mm x 3.00mm)

Download product information

RSF-2380.000-20000-3030-TR

Overview

The RSF-2380.000-20000-3030-TR is a Surface Acoustic Wave (SAW) filter manufactured by Raltron Electronics, designed for RF applications at a center frequency of 2380.000 MHz. It features a 50 Ohm input impedance and operates within a temperature range of -45°C to +85°C. The device has a maximum height of 1.2000 mm and is supplied in a tape and reel configuration.

Feature Summary

Surface Acoustic Wave technology for RF signal filtering
Designed for operation at 2.38 GHz center frequency
Compatible with surface mount assembly processes

Applications

RF front-end modules
Wireless communication systems
Mobile device signal processing

Procurement Notes

Verify the specific datasheet version from Raltron Electronics or authorized distributors to confirm exact electrical parameters and mechanical dimensions. Ensure compatibility with your PCB layout and thermal requirements before finalizing procurement decisions.

Selection Notes

Select this component when a SAW filter is required for the 2.38 GHz band with a 50 Ohm system impedance. Consider the operating temperature range and physical height constraints relative to other available RF filters in the Raltron portfolio.

Part Context

This part belongs to the Raltron SAW Filter series, which provides solutions for radio frequency interference suppression and signal conditioning in compact electronic devices.

Replacement Considerations

Consult official substitution lists from Raltron Electronics for verified alternatives. Cross-referencing with generic industry databases may not guarantee functional equivalence due to specific design variations.
