RSF2GBR560

Overview

The RSF2GBR560 is a fixed through-hole resistor manufactured by Stackpole Electronics Inc. It features a metal oxide film composition with a nominal resistance of 0.56 Ohms and a tolerance of ±2%. The component has a power rating of 2W, a maximum working voltage of 350V, and an overload voltage rating of 600V. It exhibits a temperature coefficient of ±200ppm/°C and operates within a temperature range of -55°C to +235°C. The physical dimensions are 4.50mm in diameter and 11.00mm in length.

Feature Summary

• Flame retardant coating meeting UL 94V-0 safety standards
• Metal oxide film construction for durability
• RoHS compliant and halogen-free design

Applications

• General purpose electronic circuits
• Power supply units
• Industrial control systems

Procurement Notes

Verify the specific suffix 'B' indicates the ±2% tolerance variant distinct from standard ±5% models. Confirm RoHS compliance status via official datasheets. Check lead times as availability varies. Ensure axial leaded package compatibility with PCB layouts. Validate voltage ratings against circuit requirements.

Selection Notes

Select this component for applications requiring robust metal oxide film characteristics and flame safety. The 2W power rating suits moderate current handling needs. Verify that the ±2% tolerance meets circuit precision requirements compared to standard ±5% options. Ensure operating temperatures remain within the specified -55°C to +235°C range.

Part Context

This part belongs to the RSF series of general-purpose metal oxide resistors from Stackpole Electronics. It serves as a lower-cost alternative to carbon composition and wirewound resistors. The series is designed for reliability in various industrial and commercial environments.

Replacement Considerations

RSF2JB560R offers equivalent electrical performance with ±5% tolerance.
