RT8549LGQW

$2.87

Description：IC LED DRIVER RGLTR 180MA 16WDFN
Series：-
Mfr：Richtek USA Inc.
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:3699fa6a2047 Category: LED Drivers IC Brand: Richtek USA Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：IC LED DRIVER RGLTR 180MA 16WDFN
Series：-
Mfr：Richtek USA Inc.
Package：Tape & Reel (TR),Cut Tape (CT)
Type：DC DC Regulator
Topology：Step-Up (Boost)
Internal Switch(s)：Yes
Number of Outputs：4
Voltage - Supply (Min)：4.2V
Voltage - Supply (Max)：24V
Voltage - Output：60V
Current - Output / Channel：180mA
Frequency：200kHz ~ 900kHz
Dimming：-
Applications：Backlight
Operating Temperature：-40°C ~ 85°C (TA)
Mounting Type：Surface Mount
Package / Case：16-WFDFN Exposed Pad
Supplier Device Package：16-WDFN (5x5)
Grade：-
Qualification：-

Download product information

RT8549LGQW

Overview

The RT8549LGQW is an LED lighting driver IC featuring a boost converter topology with SMBus-controlled four-channel output. It operates within an input voltage range of 4.2 V to 24 V and delivers up to 180 mA per channel. The device supports a maximum output voltage of 60 V and functions at a switching frequency of 400 kHz. Integrated protections include input undervoltage lockout, output overvoltage protection, and overcurrent protection. It utilizes PWM dimming and is housed in a WDFN-16 package.

Feature Summary

SMBus interface for digital control of the four-channel LED driver
Integrated boost converter topology for high-voltage LED applications
Comprehensive protection mechanisms including OVP, OCP, and soft-start

Applications

LED lighting systems requiring SMBus communication
Automotive interior or exterior illumination modules
Industrial backlighting solutions

Procurement Notes

Verify the specific suffix 'LGQW' against the manufacturer's official datasheet to confirm pinout and thermal characteristics. Ensure the design accommodates the specified 400 kHz switching frequency and 60 V output limit. Confirm that the WDFN-16 package footprint matches the PCB layout requirements before finalizing procurement.

Selection Notes

Select this component when a boost topology is required to drive LEDs from a low-voltage source up to 60 V. The integrated SMBus interface is suitable for systems needing precise digital control over multiple channels. Consider the 180 mA current capability and WDFN-16 package size relative to thermal management constraints in the target application.

Part Context

This part belongs to Richtek's LED lighting driver series, designed for applications requiring multi-channel control. It integrates power switches and control logic into a single compact package. The device is categorized under DC-DC controllers specifically optimized for LED driving tasks.

Replacement Considerations

Consult the official cross-reference list for verified substitutes. Generic equivalents may not support the specific SMBus protocol or 60 V output rating.
