RTAN-5006

Power Line Filter Modules Overview

The RTAN-5006 is a single-stage power line filter manufactured by TDK-Lambda, designed for three-phase delta configurations. It features a rated voltage of 500 VAC and a current rating of 6 A. The unit utilizes screw termination style and supports DIN rail mounting. This component belongs to the RTAN series and falls under the power condition sub-category.

Power Line Filter Modules Feature Summary

• Provides electromagnetic interference (EMI) and radio frequency interference (RFI) suppression for three-phase delta systems.
• Features a single-stage filtering design for effective noise reduction.
• Supports secure connections via screw termination style.

Power Line Filter Modules Applications

• Industrial machinery requiring EMI/RFI protection
• Three-phase power distribution systems
• Electrical control panels

Power Line Filter Modules Procurement Notes

Verify that the application requires a three-phase delta configuration, as this filter is specifically designed for such setups. Confirm the system voltage does not exceed 500 VAC and the load current remains within the 6 A limit. Ensure the installation environment accommodates DIN rail mounting and screw termination requirements. Cross-reference the manufacturer part number with official TDK-Lambda documentation to ensure authenticity and correct specifications.

Power Line Filter Modules Selection Notes

Select the RTAN-5006 when designing circuits involving three-phase delta power supplies that require robust EMI/RFI attenuation. Consider its 6 A current capacity and 500 VAC rating against the specific electrical demands of the target equipment. Evaluate the physical space available for DIN rail installation and verify compatibility with existing wiring methods using screw terminations.

Power Line Filter Modules Part Context

This component is part of the RTAN series from TDK-Lambda, which specializes in power line filters. The RTAN series offers various models tailored for different phase configurations and current ratings. The RTAN-5006 specifically addresses the needs of three-phase delta applications, providing essential noise filtering to maintain signal integrity and compliance in industrial power environments.

Power Line Filter Modules Replacement Considerations

Consult official TDK-Lambda documentation for verified substitute part numbers. Ensure any replacement matches the three-phase delta requirement, 500 VAC rating, and 6 A current capacity. Verify mechanical compatibility with DIN rail mounting and screw termination styles before substitution.
