RTEN-5200J9J3-00

Power Line Filter Modules Overview

The RTEN-5200J9J3-00 is a three-phase delta EMC/EMI power line filter module rated for 200 A and 500 VAC. Designed for chassis mounting, it utilizes screw termination style for secure electrical connections. The unit features a low-profile package with nominal dimensions of 195 mm in length and 390 mm in width. It serves as a single-stage solution for mitigating electromagnetic interference in high-current industrial power distribution systems.

Power Line Filter Modules Feature Summary

• Single-stage EMI/EMC filtering architecture
• Chassis mount construction with screw terminations
• Low-profile physical design

Power Line Filter Modules Applications

• Industrial power distribution panels
• High-current motor drive systems
• Factory automation equipment

Power Line Filter Modules Procurement Notes

Verify the specific suffix J9J3 against the manufacturer's current datasheet to confirm terminal configuration and certification status. Ensure the application voltage does not exceed 500 VAC or 500 VDC. Confirm that the mechanical footprint aligns with the 195 mm by 390 mm nominal dimensions before integration into the assembly.

Power Line Filter Modules Selection Notes

Select this component when a single-stage solution is required for three-phase delta networks carrying up to 200 A. The low-profile form factor is suitable for applications with constrained vertical clearance. Verify that the installation environment supports chassis mounting and that the screw termination method matches the available busbar or cable lugs.

Power Line Filter Modules Part Context

This model belongs to the RTEN-5200 series of power line filters from TDK-Lambda. The series provides EMC suppression for three-phase systems. The RTEN-5200J9J3-00 variant specifically addresses high-current requirements within this family, offering a standardized interface for industrial noise reduction.

Power Line Filter Modules Replacement Considerations

Consult official substitution lists for compatible modules within the RTEN series. Verify that any alternative part maintains the 200 A rating and three-phase delta compatibility.
