Product Detailed Parameters
- Description：OPTOISOLATOR 3.75KV 1CH TRANS
- Series：-
- Mfr：Renesas Electronics Corporation
- Package：Strip
- Number of Channels：1
- Voltage - Isolation：3750Vrms
- Current Transfer Ratio (Min)：200% @ 2mA
- Current Transfer Ratio (Max)：850% @ 2mA
- Turn On / Turn Off Time (Typ)：10µs, 150µs
- Rise / Fall Time (Typ)：8µs, 120µs
- Input Type：DC
- Output Type：Transistor
- Voltage - Output (Max)：40V
- Current - Output / Channel：50mA
- Voltage - Forward (Vf) (Typ)：1.65V
- Current - DC Forward (If) (Max)：25 mA
- Vce Saturation (Max)：300mV
- Operating Temperature：-40°C ~ 135°C
- Mounting Type：Surface Mount
- Package / Case：4-SMD, Gull Wing
- Supplier Device Package：-
- Grade：Automotive
- Qualification：AEC-Q100
Download product information
Overview
The RV1S2752QKCSP-1000N#SC0 is an automotive-grade high isolation voltage photocoupler manufactured by Renesas Electronics. It features a single channel configuration housed in a compact 4-pin SOP (SO4) surface-mount package. The device provides robust electrical isolation with a maximum continuous output current of 10 mA and a propagation delay of 60 ns. It operates within a temperature range of -40°C to +125°C, ensuring reliability in demanding automotive environments.
Feature Summary
- High isolation voltage capability for safe signal transmission
- Automotive qualification compliant with industry standards
- Compact 4-pin SOP package design for space-constrained applications
Applications
- Automotive safety systems requiring galvanic isolation
- Chassis control modules
- Electric vehicle power electronics interfaces
Procurement Notes
Verify the specific suffix N#SC0 against official Renesas documentation to confirm tape-and-reel packaging specifications. Ensure the component meets AEC-Q101 grade requirements for the target automotive application environment. Cross-reference the datasheet revision date to validate parameter consistency before integration into production designs.
Selection Notes
Select this component when high isolation voltage and automotive reliability are required in a minimal footprint. The SO4 package suits applications with strict board space limitations. Consider the 60 ns propagation delay for timing-sensitive digital signal isolation tasks within automotive networks.
Part Context
This part belongs to the RV1S series of automotive photocouplers designed for high-voltage isolation. It complements Renesas' broader portfolio of safety-critical components used in electric vehicles and advanced driver assistance systems. The series emphasizes functional safety compliance and long-term stability under thermal stress.
Replacement Considerations
Consult official Renesas substitution lists for direct pin-compatible alternatives. Verify that any substitute maintains the same isolation voltage rating and automotive qualification level to ensure system integrity.
